Eminence Legend CA10 - 10" Speaker 200 W 32 Ohm

Made famous as an OEM model in many popular bass guitar cabinet brands, this highly sought after design features a truncated cast frame chassis for tight fitting in your 2x, 4x and 8x10 cabinet. Loud and clear bass guitar tone with legendary growl.

Hmotnosť

222,02

180,50 € bez DPH

Pridať
do ponuky

Uvedená cena je orientačná.
Vložte tovar do košíka a odošlite pre vypracovanie aktuálnej cenovej ponuky.

Product typeLoudspeaker ChassisTypeGuitarsNominal Diameter10 ", 254 mmVoice Coil2 ", 51 mmOverall diameter266.7 mmPitch Circle Diameter- mmCut- out Measurement228.9 mmDiameter of fixing holes- mmDepth- mmNominal Impedance32 Ohm(s)Nominal Load Capacity175 Wmaximum rated load350 WSensitivity (1 W / 1 m)95.8 dBFrequency response50 - 3200 HzVoice Coil MaterialcopperMagnetFerriteThiele & Small ParameterFs (Resonance Frequency)55 HzRe (DC resistance)22.12 Ohm(s)Qms (mechanical quality)7.16Le (inductance of the voice coil)2.07 mHQes (electrical quality)0.58Qts (overall quality)0.53Vas (equivalent volume)47.64Mms (moving mass)29 gBL (power factor)19.74 T/mXmax (maximum displacement)3.02 mmCms (elasticity of the suspension)0.28 mm/NSd (membrane area)350.1 cm2Weight3,99 kg
