LD Systems VIBZ 6 D - 6-kanálová mixážna konzola s DFX

• 6-kanálový mixér so 16 digitálnymi efektmi
• 2 kanály pre mikrofón s 3-pásmovým EQ
• 2 mono kompatibilné stereofónne kanály s 2-pásmovým ekvalizérom
• Výstupy Master, Monitor a slúchadlá
• Bezpečne upevnené externé napájanie
• Šírka 209 mm
• Výška 68 mm
• Hĺbka 260 mm
• Hmotnosť 1,45 kg

Na objednávku

1,45

Hmotnosť

pdf4,08 MB

User´s Manual

CENA:

na dopyt

Pridať
do ponuky

Uvedená cena je orientačná.
Vložte tovar do košíka a odošlite pre vypracovanie aktuálnej cenovej ponuky.

The VIBZ 6 is a compact 6-channel mixer which is perfectly suited to entertainers, small bands, home recording and installations. It features two balanced microphone inputs with high-quality preamps, phantom power and 3-band EQ with +/-15 dB adjustment scope, two stereo line inputs with 2-band EQ, which are mono-compatible, and an effects loop.

The master section of the VIBZ 6 is equipped with adjustable monitor outputs, a headphone jack and 16 digital effects presets, which are foot-switchable. The mixer also has inputs and outputs for recording and playback devices, is extremely easy to use and offers a warm differentiated sound. The external power supply can be screwed on tightly.

A foot switch for the effects section and an adapter for mounting the VIBZ 6 on microphone stands are available as accessories.

• Product type: Mixers • Type: Live • Channels: 6 ○ MAIN SECTION • AUX / Effects Send Channels: 1 • AUX / Effects Send Connectors: 6.3 mm stereo jack unbalanced • Stereo AUX Return Channels: 1 x stereo • Stereo AUX Return Connectors: 2 x 6.3 mm TRS • Stereo Tape Out Channel: 1 x stereo • Stereo Tape Out Connectors: 2 x RCA (Cinch) • Stereo Tape In Channel: 1 x stereo • Stereo Tape In Connenctors: 2 x RCA (Cinch) • Unbalanced stereo Main Outputs: 1 • Unbalanced stereo Main Output Connections: 6.3 mm TRS • Unbalanced Stereo Main Out Impedance: 120 Ohm(s) • Max. Unbalanced Stereo Main Out Level: +20 dBu • Stereo Control Room Out: 1 • Stereo Control Room Out Connectors: 6.3 mm stereo jack unbalanced • Headphones ouput: 1 • Headphones outputs: 6.3 mm TRS • Digital Effects Processor: Yes, 24-bit AD/DA Resolution • Number of Presets: 16 • Footswitch Connector DFX Mute: 6.3 mm TRS • Main section controls: 2-track Assignment (Main, Contr. Room), 2-track In Volume, DFX Mute Schalter, DFX Presets, DFX To Main Volume, Master Volume, Phantom Power, Phones / Control Room Volume, Stereo Return Volume • Indicators: 4-segment Level Meter, Channel Peak, DFX Peak / Mute, Phantom Power, Power • Power supply: 18V DC - 1 A, External PSU, 230 V • Width: 209 mm • Height: 68 mm • Depth: 260 mm • Weight: 1,42 kg
