Analog Way® Dual-Link DVI, DP, HDMI and 3G-SDI 4K@30 output expansion card

4K @ 30Hz výstupné video rozhranie pre VIO 4K multiformat converter.
Rozširujúca karta OPT-OUT-VIO4K je výstupné video rozhranie pre VIO 4K schopné podporovať formáty až do 4K @ 30Hz 4: 4: 4 10 bitov s Dual-Link DVI, DisplayPort, HDMI, 3G-SFP ako aj pripojenie 3G-SDI.
Dual-Link DVI
Up to 7.92Gbps bandwidth
Up to 2560x1440@60Hz 4:4:4 8 bits
HDCP compliant
RGB 4:4:4; YCbCr: ITU-R BT.601 and ITU-R BT.709 color spaces
HDMI
Up to 10.2Gbps bandwidth
Up to UHD/4K@30Hz 4:4:4 8 bits
Up to 2560x1440@60Hz 4:4:4 10 bits
HDCP 1.4 compliant
RGB 4:4:4; YCbCr: ITU-R BT.601, ITU-R BT.709 and ITU-R BT.2020 color spaces
DisplayPort
Up to 10.8Gbps bandwidth
Up to UHD/4K@30Hz 4:4:4 10 bits
HDCP 1.3 compliant
RGB 4:4:4; YCbCr: ITU-R BT.601 and ITU-R BT.709 color spaces
3G-SDI and 3G-SFP cage
Up to 6Gbps bandwidth
Up to 2160@30Hz 4:2:2 10 bits
Support of 3G-SDI Level A and Level B
YCbCr: ITU-R BT.601 and ITU-R BT.709 color spaces
