Martin MAC Aura XB
MARTIN MAC AURA XB oceňované, inovatívne, kompaktné Wash LED svetlo posunulo kvalitu svetelných efektov na ďalšiu vyššiu úroveň.S mnohými novými funkciami, ktoré boli prvýkrát predstavené s aplikáciou MAC Quantum Wash ™. MAC Aura XB ponúka nielen dodatočný jas, ale aj nový špičkový systém zmiešavania farieb a optimalizovaný dizajn šošoviek pre ostrejšie lúče a rovnomernejší Wash efekt. Martin je unikátny a patentovaný Eye-candy Aura Effect ™ .
Super jasné Wash light s plne premixovanou farbou
Kompaktný dizajn a nízka hmotnosť 6,5 kg
Vysoká účinnosť, nízka spotreba energie, dlhá životnosť
Vstavaný motor FX
10 až 60 ° zoom
Výstup 6 000 lúmenov
Rýchly pohyb
The MAC Aura XB takes an award-winning, innovative, compact LED wash light to the next level, incorporating many new features first introduced with the MAC Quantum Wash™. Not only does the MAC Aura XB offer additional brightness, it also features a new superior color mixing system and an optimized lens design for tighter beams and more even washes. Martin's unique and patented Eye-candy Aura Effect™ is also part of the package.
Super bright single lens wash with fully premixed color
Compact design and low weight
High efficiency, low power consumption, long service life
Features
Super-bright single-lens wash with fully premixed color
Broad color palette, RGBW color mixing
Eye-candy Aura Effect™
Uniform shades
Built-in FX engine
10 to 60° uniform zoom
6000 Lumens output
Rapid movement
Compact, low weight design (6.5 kg)
High efficiency, low power consumption, long lifetime
Tech Specs
Physical
|
Length (across yoke): | 302 mm (11.9 in.) |
|
Width (across yoke): | 302 mm (11.9 in.) |
|
Height (head straight up): | 360 mm (14.2 in.) |
|
Weight (without accessories): | 6.5 kg (14.4 lbs.) |
Dynamic Effects
|
Beam color mixing: | RGBW |
|
Aura (secondary lens array illumination) color mixing: | RGB |
|
Beam color temperature control: | CTO, variable 10 000 - 2500 K |
|
Beam and aura electronic 'color wheel' effect: | 33 LEE-referenced colors plus white, variable-speed color-wheel rotation effect and random color |
|
Beam and aura independent shutter effects: | Electronic, with regular and random pulse, burst and strobe effects |
|
Pre-programmed effects: | Range of independent and synchronized Beam and Aura FX, two combinable |
|
Electronic dimming: | Independent beam and aura, four dimming curve options |
|
Zoom: | 10° - 60° (one-tenth peak angle) |
|
Pan: | 540° |
|
Tilt: | 232° |
|
Pan and tilt speed: | Adjustable via onboard control panel and DMX |
Control and Programming
|
Control options: | Independent or synchronized Beam and Aura control |
|
Control system: | DMX, RDM |
|
Control resolution: | 8-bit, with 16-bit control of pan & tilt |
|
DMX channels: | 14/25 |
|
Setting and addressing: | Control panel with backlit graphic display |
|
DMX compliance: | USITT DMX512-ARD |
| M compliance: | ANSI/ESTA E1.20 |
|
Transceiver: | RS-485 |
|
Firmware update: | Via DMX with Martin™ USB Duo DMX Interface Box |
|
Optics and Photometric DataLight source: | 19x 15W RGBW LED Array System |
|
LED refresh rate: | Beam 1200 Hz, Aura 4395 Hz |
|
Minimum LED lifetime: | 50 000 hours (to >70% luminous output)* |
|
Total luminous output (wide, one-tenth peak): | 6000 lumens |
|
Total luminous output (narrow, one-tenth peak): | 4300 lumens |
|
Video compatibility: | Designed for use with HD/high-speed video cameras |
*Figure obtained under manufacturer´s test conditions
Construction
|
Color: | Black |
|
Housing: | High-impact thermoplastic, flame-retardant to UL 94 5VA |
|
Protection rating: | IP20 |
Installation
|
Mounting points: | M12 hole for rigging clamp, attachment points for surface-mounting bracket |
|
Orientation: | Any |
|
Minimum distance to combustible materials: | 200 mm (8 in.) from fixture |
|
Minimum distance to illuminated surfaces: | 1 m (3 ft. 4 in.) from fixture |
|
Location: | Indoor use only, must be fastened to surface or structure |
Connections
|
AC power: | Neutrik PowerCON TRUE1 NAC3PX dual socket |
|
AC power input socket: | Accepts Neutrik PowerCON TRUE1 NAC3FX-W cable connector |
|
AC power thru socket: | Accepts Neutrik PowerCON TRUE1 NAC3MX-W cable connector |
|
DMX data in/out: | 5-pin locking XLR |
Electrical
|
Maximum power consumption: | 400 W |
|
Power supply unit: | Auto-ranging electronic switch mode |
|
AC power: | 100-240 V nominal, 50/60 Hz |
|
Typical half-cycle RMS inrush current: | 10.7 A |
|
Power consumption, all effects static, zero light output: | |
