CONTROL and CONNECTIONS
• Personalities: | Single mode with 6 control channels |
• DMX 512, 5 pin In & Out connector / Art-Net
• Control signal USITT DMX 512, RDM, Art-Net, sACN
• Display Graphic LCD backlit b/w Display
• Display battery Long life self-charging buffer battery
• Pan/Tilt Resolution 16 bit
• Ethernet Input
DYNAMIC EFFECTS
• Pan range 540°
• Tilt (continuous movement from min 0.08rpm to max 40 rpm) range 360
HARDWARE and SOFTWARE
• Long life self-charging battery
• Function reset via on-board menu
• Function reset from the lighting desk
• “AUTOTEST” function from menu
• Electronic monitoring with status error reporting and logging
• DMX level monitoring on all channels
• Internal data transmission diagnostics
• Firmware upgrade with no power (CPU only)
• Firmware upload from another fixture (CPU only)
• Firmware Upgrade via Web Server
• Protocols/Functions: | RDM, Web Server, ArtNet |
• Extremely reliable communication RS485 bus
HOUSING
• Aluminum and steel structure with plastic covers
• Two side handles for transportation
• Device locking PAN and TILT mechanisms for transportation and maintenance
• Optional safety chain
WORKING POSITION
• Working in any position
• Optional safety chain
Hanging system: | with fast-lock omega clamps (1/4 turn) on the base |
ELECTRICAL
• Operating Voltage: | 100-240V, 50/60 Hz |
• Power
Supply: | Electronic auto range with active PFC |
• Max Power consumption: | 750VA |
