MAGMATIC Prisma Par 20

PRISMA PAR 20 ™ je exteriérové wash UV svietidlo s krytím IP65, ktoré produkuje maximálny UV výkon 365 nm s nulovým viditeľným svetlom. Medzi vlastnosti patrí 20-stupňový úzky uhol lúča, užívateľsky príjemný digitálny 2,5 palcový dotykový LCD ovládací panel, intuitívne ovládanie DMX-512 a RDM,duálne nastaviteľné montážne držiaky, odolný hliníkový kryt, IP65 DMX 5pin XLR a uzamykateľné pripojenie vstupu/výstupu.

Na objednávku

2,40

Hmotnosť

pdf3,32 MB

Prisma Par 20 User Manual

pdf824 kB

Prisma Par 20 Specification Sheet

CENA:

na dopyt

Pridať
do ponuky

Uvedená cena je orientačná.
Vložte tovar do košíka a odošlite pre vypracovanie aktuálnej cenovej ponuky.

The PRISMA PAR 20™ is an exterior IP65 rated UV wash par luminaire that produces 365nm peak true UV output with zero visible light. Features include a 20 degree narrow beam angle, a user friendly digital 2.5 inch LCD touch screen control panel, intuitive DMX-512 and RDM control, dual adjustable mounting yokes, a durable aluminium housing, IP65 DMX 5pin XLR and locking power in/out connections.

FEATURESIP65 Rated Exterior High-Power UV Wash Par Luminaire20 Degree Narrow Beam Angle365nm Peak True UV WavelengthZero Visible Light OutputSOURCE(12) 2W High Power UV Diode LEDs20,000 Hour Average LED Life**Test lab conditions. May vary depending on several factors including but not limited to:

Environmental Conditions, Power/Voltage, Usage Patterns (On-Off Cycling), Control, and Dimming. PHOTOMETRIC DATA20 Degree Narrow Beam Angle365nm True UV Peak Wavelength EFFECTSHigh Speed Electronic StrobeVariable Dimming Curve Modes CONSTRUCTIONRugged IP65 Rated HousingDual Adjustable Mounting Yokes CONTROLMultiple DMX Channel ModesOnboard 4 Button Touch Control PanelDMX-512 and RDM Protocol Support CONNECTIONSLocking IP65 5pin XLR Connector In/OutLocking IP65 Power Connector In/OutWith Wired Digital Communication Network SIZE / WEIGHTLength

5.9 in. (150mm)Width

8.27 in. (210mm)Vertical Height

9.05 in. (230mm)Weight

6.0 lbs. (2.7kg) ELECTRICALAC100-240V 50-60Hz27W Max Power Consumption THERMAL14°F to 113°F (-10°C to 45°C)Air CooledPRISMA PAR 20™ is an exterior IP65 rated UV wash par luminaire that produces 365nm peak true UV output with zero visible light. Features include a 20 degree narrow beam angle, a user friendly digital 2.5 inch LCD touch screen control panel, intuitive DMX-512 and RDM control, dual adjustable mounting yokes, a durable aluminium housing, IP65 DMX 5pin XLR and locking power in/out connections.
