PRISMA MINI BAR 20™ is is an IP65 rated exterior UV wash bar luminaire that produces 365nm peak true UV output with zero visible light, and an impressive 20 degree beam angle. Powered by the PRISMA DRIVER 8™ or PRISMA DRIVER 8IP™ 'Not Included'
| FEATURESIP65 Rated Exterior High-Power UV Wash Bar Luminaire20 Degree Narrow Beam Angle365nm True UV Peak WavelengthZero Visible Light OutputIP Rated Power/Data Pigtail Cable AttachedSOURCE(10) 2W High Power UV Diode LEDs20,000 Hour Average LED Life**Test lab conditions. May vary depending on several factors including but not limited to: | Environmental Conditions, Power/Voltage, Usage Patterns (On-Off Cycling), Control, and Dimming. PHOTOMETRIC DATA20 Degree Narrow Beam Angle365nm True UV Peak Wavelength EFFECTSHigh Speed Electronic StrobeVariable Dimming Curve Modes CONSTRUCTIONRugged IP65 Rated Aluminum HousingAdjustable Mounting Brackets (x2) CONTROLMultiple DMX Channel ModesDMX-512 and RDM Protocol Support CONNECTIONS6 ft (1.8m) 2-Conductor 14 Gauge IP Rated Power/Data Pigtail Cable AttachedWith Wired Digital Communication Network SIZE / WEIGHTLength | 23.42 in. (595mm)Width | 3.93 in. (100mm)Vertical Height | 4.13 in. (105mm)Weight | 4.9 lbs. (2.2kg) ELECTRICALAC100-240V 50-60Hz25W Max Power Consumption THERMAL14°F to 113°F (-10°C to 45°C)Air CooledPRISMA MINI BAR 20™ is is an IP65 rated exterior UV wash bar luminaire that produces 365nm peak true UV output with zero visible light, and an impressive 20 degree beam angle.Powered by the PRISMA DRIVER 8™, features 2 adjustable mounting brackets, a durable aluminium housing, and a 6 ft (1.8m) 2-Conductor 14 Gauge IP rated power/data pigtail cable. |
