MAGMA PRIME™ is a water-based hazer with advanced technology providing a high volume dry haze effect with low fluid consumption. The new HPA (high pressure air) pump technology reduces the risk of heater clogging. Features includes a self-cleaning and energy-saving “Sleep” mode, an easy to use onboard LCD touch screen control panel, intuitive DMX-512 and RDM control, a durable aluminium housing, and optional wired and wireless remote control options.
FEATURES700W Water-Based Hazer4,000 CFM* (cu ft/min.) (113 m3/min*) OutputAdvanced HPA (high pressure air) Pump TechnologyEnergy Saving Mode with Auto-Clean ProcessCompact Light Weight Robust DesignOnboard LCD Touch Control PanelOptional E-FLY Wireless DMX TransceiverOptional RF Wireless and Wired Remotes*approximatePERFORMANCERated Power: 700WMax Output: 4,000 CFM* (cu ft/min.) (113 m3/min*)Ready Time: Initial = 5 Minutes*Fluid Capacity: 0.345 gallons (1.3 liters)Fluid Consumption: 0.115 oz/min (3.4 ml/min)*approximateCOMPATIBLE FLUIDAtmosity Extreme Filtered Fog Fluid (AEF-4L)CONSTRUCTIONThermally Protected Heat ExchangerAdvanced HPA (high pressure air) Pump TechnologyEnergy Saving Mode with Auto-Clean ProcessSealed Fluid ReservoirExternal Visual Fluid Level DetectionCompact Light Weight Mobile DesignCONTROL3 DMX Channel Modes (1 / 3 / 5)Onboard LCD Touch Control PanelDMX-512 and RDM Protocol SupportOptional E-FLY Wireless DMX TransceiverOptional RF Wireless and Wired RemotesCONNECTIONSLocking 5pin XLR Connector In/OutIP65 Locking Power Connector InWith Wired Digital Communication NetworkSIZE / WEIGHTLength: 14.0 in. (355.6mm)Width: 6.0 in. (152.4mm)Height: 16.0 in. (406.4mm)Weight: 22.5 lbs. (10.2kg)ELECTRICALAC 100-120V - 50/60Hz9A (NFB)Max Power Consumption: 720WTHERMALMaximum Ambient Temperature (Ta max) 104°F (40°C)Exterior Surface Temperature, Steady State: 122°F (50°C)
